Galvanized Steel Fiber Hooked End Type for Road Highway Slope Bridge Tunnel Airport Port Railway Sleeper

Product Description:

The end hook bonded steel fiber are prominent: good dispersion, tensile strength not less than 1000MPa, shape of the end hook is not easy to pull out, economy, and good water solubility of the bonded steel fiber.



Material properties: high quality and high speed wire.



The bonded steel fibers are widely used in factory floors, highways, bridges, airport runways, tunnels, pipelines, linings of infrastructure, ports and

wharves, marine engineering, nuclear test bases, rocket launch bases and earthquake resistant buildings.



Steel Fiber Hooked End Type can ensure that the fibers do not agglomerate and disperse evenly in concrete mixing, and can improve the impact resistance and fatigue resistance of concrete and the impermeability of concrete. Because of its high tensile strength, good toughness and low price, compared with othershapes of steel fibers, its tensile strength, compressive strength and flexural strength have been greatly improved, which is suitable for some keyanti-seismic and anti riot structural projects. It has been widely used in roads, highway slope protection bridges, tunnels, airports, ports, railway sleepers and so on.



Specification:



Item	Diameter (mm)	Length (mm)	L/D	TS (MPa)±7.5%	Type
80/60	0.75	60	80	1100, 1800	Glued
80/50	0.62	50	80	1200	Glued
65/60	0.9	60	65	1000, 1800	Glued
65/35	0.55	35	65	1200	Glued
