Product Details:
|
Product Name: | PP Twisted Bunchy Fiber | PP Twisted Bunchy Fiber Color: | Gray |
---|---|---|---|
Type: | Twisted Bunchy | PP Twisted Bunchy Fiber Length: | 40/48/54mm |
PP Twisted Bunchy Fiber Raw Material: | 100% Polypropylene | PP Twisted Bunchy Fiber Dia: | 0.7mm (+/-5%) |
PP Twisted Bunchy Fiber Crack Elongation: | 15% Min | PP Twisted Bunchy Fiber Density: | 0.91 (g/cm3) |
PP Twisted Bunchy Fiber Melt Point: | 170℃ | PP Twisted Bunchy Fiber Break Strength: | 600Mpa |
PP Twisted Bunchy Fiber Elastic Modulus: | ≥5000Mpa | PP Twisted Bunchy Fiber Acid&Alkali Resistance: | Excellent |
Highlight: | 54mm PP Twisted Bunchy Fiber,Crack-Resistant PP Twisted Bunchy Fiber |
54mm PP Twisted Bunchy Fiber Common Crack-Resistant Requirement
PP Twisted Bunchy Fiber Introtuction:
PP twisted bunchy fiber is a kind of concrete additive, using polyolefin as raw material, its rough surface is processed by special parallel thread extrusion and twisting process. It is often used to strengthen concrete instead of steel fiber
PP Twisted Bunchy Fiber Feature:
The pp twisted bunchy fiber which have high fracture strength, good dispersion and strong binding force.
PP Twisted Bunchy Fiber Applying Instruction:
1. Mixing ratio: It is generally recommended that the concrete content per square meter should be more than 2. 7kg (volume ratio 0.3%), and the reinforcement should be 5.5kg
2. Length: The usual crack resistance requires a fiber length of 54mm
3. As shown. Mix ratio: The proportion of concrete usually does not change, in order to crack resistance requirements, it is recommended that the polymer fiber and PP fiber mesh in the form of 1:1 volume ratio (per square meter of cement concrete 0.9kg fiber mesh) used in combination.
4. Use: dual axis horizontal forced mixer preferred.
5. Mixing process: the gravel, fiber, sand in turn into the blender. After the fiber is fully developed, add cement and water and stir normally. The added material can be added in the same way as ordinary concrete, but the mixing time needs to be extended appropriately to ensure that the fibers are fully mixed.
6. Styling and maintenance: no special requirements, can be 30 seconds along the vibration time, the maintenance method is the same with ordinary concrete.
PP Twisted Bunchy Fiber Specification:
Raw Material | PP/PE | Density (g/cm3) | 0.91 |
Elastic Modulus (Mpa) | >=5000 | Length (mm) | 40,50, 54 |
Equivalent Diameter (mm) | 0.3+/-0.05 | Break Tensile Ratio (%) | 15min |
Break Strength (Mpa) | >=600 | Alkali & Acid resistance | Strong |
PP Twisted Bunchy Fiber Related Goods:
PP Mesh Fiber PP Micro Fiber PP Macro Fiber Embossed
PP Macro Fiber Wave PP Mesh Fiber Micro Steel Fiber
Cetificate:
